Features

Project Stellar Features

• Built-in tools for system troubleshooting, configuration, hard-drive setup, etc.
• Automatic network based system updating.
• Kernel level ODE. (ISO Loading)
• Compressed ISO Loading. (CISO)
• Additional controller support. (Xbox One)
• Network loading of ISOs and virtual HDD images.
• Titan+ support. Supports legacy configured drives and Titan formated HDDs for up to 16TBs of native storage.
• Auto optimal UDMA timing. Up to UDMA5 autoconfigured, verifed, and tested on boot.
• Native ATA TRIM support.
• True no-DVD drive bypass. No external modifications required.
• Support for 64MB, 128MB, and 256MB RAM configurations.
• Automatic system time updating via network on boot.
• Analog video improvements and fixes with feature parity of the XboxHD+.
• Native boot animation in 720P.
• Native force 480P with HD+ fixes.
• Insignia enhancments.
• Advance fan control.
• Kernel debugger over USB.
• GDB debugger via USB.
• And so much more...

Project Stellar Plus Features

• Wireless Controller Support
  Connect up to seven wireless controllers at once for a total of eleven supported controllers (four USB and seven wireless). Compatible with a wide range of Bluetooth Classic and BLE controllers through BlueRetro.
• Remote Power On
  Power on your Xbox directly from a wireless controller.
• Automatic Port Mapping
  Wireless controllers are automatically mapped to available virtual ports for seamless gameplay and homebrew use.
• Wi-Fi Connectivity
  Enables StellarOS firmware updates directly over the network.
  Wi-Fi functionality is limited to firmware updates at this time. Future features may be added in upcoming StellarOS releases.
• Built-in Speaker:
  Adds sound feedback for pairing, system notifications, and other actions.
• BlueRetro Integration
  Full support for button remapping, rapid fire, macros, and advanced controller features.
• Stellar RGB Integration
  Adds lighting control and synchronization with Stellar RGB hardware.

Project Stellar Plus Exclusive Features

• Fully redesigned hardware
• Integrated wireless system (no separate board)
• Optimized LPC interface and optional LPC passthrough
• Faster co-processor and SD card interface
• Improved overall performance and responsiveness
• Additional hardware headroom for future features

Kit Contents

• Project Stellar Board
• Mounting hardware
• 2x8 gold-plated pin header
• Easy d0 Flex for 1.0 - 1.5 installs
• Easy LPC Rebuild QSB for 1.6 installs

Screenshots

Resources

	Installation Guide
	Knowledge Base
	Firmware Recovery
	Troubleshooting
	Upgrading to Stellar XboxHD+

FAQ

What is the difference between Project Stellar and Project Stellar Plus?
Stellar Plus is a complete redesign that includes integrated wireless hardware, faster performance, and expanded functionality. It removes the need for the separate wireless upgrade board and is built for future features.

Can I use the same StellarOS firmware?
Yes. Both Stellar and Stellar Plus use the same StellarOS firmware, although certain features may be exclusive to Stellar Plus.

Will my current Stellar accessories still work?
Yes. Accessories like Stellar RGB and future Stellar expansion boards are fully supported.

Does Stellar Plus require soldering?
Installation is straightforward and similar to the original Stellar. Basic soldering is required.

Can I still use wired controllers?
Yes. You can use up to four wired USB controllers along with seven wireless controllers for a total of eleven.

Will there be future updates?
Absolutely. StellarOS is under active development, and additional features may be introduced in future firmware updates. Certain experimental features may be disabled in select builds during public testing.
